Raptor 3D Printer Kit

Description

The CoreXY design provides higher speeds and more accurate printing to ensure high quality prints in less time. Quad linear rods coupled with dual lead screws stabilize the bed. Quality linear rails provide smooth movement so parts come out clean and precise.

The powerful motherboard with silent TMC2209 motor drivers promises excellent performance while keeping the noise level to a minimum. The motherboard is open source, so the user can install any firmware they choose, although Klipper is recommended.

3D Printer Properties:

• Mechanical Arrangement: CoreXY
• Assembly: DIY Kit
• Build Volume: 150 x 150 x 200mm
• Feeder System: Bowden
• Print Head: Single nozzle
• Print Speed: Up to 300mm/s
• Travel Speed: 500mm/s
• Resolution: 0.1-0.3mm Layer Height
• Supply Voltage: Input: 110/220V 50/60Hz, Output: 24V 350W
• Max Hotend Temperature: 330°C
• Max Bed Temperature: 130°C
• Heat Bed Type: 24V insulated
• Nozzle Size: 0.4mm Default
• Firmware: Klipper (standard) or any open source
• Connection: USB Interface, MicroSD Card
• Input Shaping/Resonance Compensation
• Bed Leveling: manual
• Sensorless Homing: X/Y Axes
• Removable Build Platform

Materials:

• Filament Diameter: 1.75 mm
• Filament Materials: PLA, ABS, ASA, PETG, Flexibles, HIPS, PC, NYLON

Electronics:

• High Quality Motherboard
• TMC2209 Motor Drivers
• High Torque Stepper Motors
• Orbiter Extruder

Software:

• Slicer: Any, Ideamaker (preferred)
• Operating System: Windows, Mac OS, Linux
• File Types: STL, 3MF, OBJ

Dimensions:

• Printer Dimensions: 327 W x 404 D x 480 H mm

Additional Hardware Needed:

• Linux Computer (i.e. PC, Laptop, Raspberry Pi, etc.) – required for Klipper
• Screen – if not using a web interface with Klipper or using a different firmware
